A/D covered by aluminium plate,prevent PCB from static and moisture
Overload and transport protection devices (with anti-cockroach design)
Auto shut off/ auto backlight
OK printing function
Resolution up to 1/15000(standard) or 1/30000(optional)
Zero/tare/pre-tare/zero tracking/accumulation (99 pieces)/auto unit weight recomputing/part counting/sampling/check quantity functions
RS-232/Relay interface/U-KEY connector/Blue Tooth 2.0/Blue Tooth serial port/USB Module / USART (optional)
Ideal for applications including document distribution,shipping and receiving/inventory management/in-process parts counting/pre-packing parts/ warehouse or any other use
One-click Printing, Overload and Transmission Protection Device
| Model | JCL-1.5K | JCL-3K | JCL-6K | JCL-15K | JCL-30K |
| Capacity(kg) | 1.5 | 3 | 6 | 15 | 30 |
| Division(g) | 0.1/0.05 | 0.2/0.1 | 0.5/0.2 | 1/0.5 | 2/1 |
| Countable unit weight(g) | 0.02 | 0.02 | 0.04 | 0.1 | 0.2 |
| Weighing units | g/lb/pcs | Kg/lb/pcs | |||
| Display(mm) | 6/5/6 digits,19mm digit height,LCD display with green backlight | ||||
| Weighing pan(mm) | 294×228(stainless steel) | ||||
| Weight | Net weight:4.48kg,Gross weight:5.04kg | ||||
| Power supply | AC 110V/220V (AC±10%)/Rechargeable battery(6V/4 AH) | ||||
